Crawler excavator
SHANTUI SR36SR – Crawler Excavator
TypeZero-Tail Swing
Operating weight3,880 kg
EngineYANMAR 3TNV88F (18.2 kW / 24 hp)
Bucket capacity0.12 m³
Hydraulic linesyes
The SHANTUI SR36SR delivers greater power and productivity while maintaining the advantages of a compact excavator. Its advanced hydraulic system and extended working range ensure efficient performance on construction, municipal, and infrastructure projects.
The compact design makes it ideal for urban job sites.
The compact design makes it ideal for urban job sites.
TypeZero-Tail Swing
Operating weight3,880 kg
EngineYANMAR 3TNV88F (18.2 kW / 24 hp)
Bucket capacity0.12 m³
Hydraulic linesyes
Track typerubber
Swing boomyes
Hydraulic systemLoad-Sensitive
Overall dimensions4880x1740x2550 mm
Maximum digging force30.4 kN
Maximum digging height4910 mm
Maximum digging reach5500 mm
Maximum digging depth3075 mm
Swing speed9.0 rpm
Travel speed2.4/4.4 km/h
Fuel tank capacity50 L
Fuel typediesel
- Low running costs and high reliability.
- Genuine spare parts readily available.
- Factory warranty and full technical support.
