Crawler excavator
SHANTUI SE60 – Crawler Excavator
Typestandard
Operating weight5,960 kg
EngineKUBOTA V2607 (36 kW / 50 hp)
Bucket capacity0.22 m³
Hydraulic linesyes
The SHANTUI SE60 is a versatile excavator that combines power, precision, and fuel efficiency. Its load-sensitive hydraulic system delivers smooth and accurate operation, while the durable construction ensures reliable daily performance.
It is an ideal solution for construction, roadwork, and utility projects.
It is an ideal solution for construction, roadwork, and utility projects.
Typestandard
Operating weight5,960 kg
EngineKUBOTA V2607 (36 kW / 50 hp)
Bucket capacity0.22 m³
Hydraulic linesyes
Track typesteel
Hydraulic systemLoad-Sensitive
Emission standardEU Stage IIIA
Overall dimensions5855x1880x2675 mm
Maximum digging force48 kN
Maximum digging height5785 mm
Maximum digging reach6200 mm
Maximum digging depth3850 mm
Swing speed11.0 rpm
Travel speed2.3/4.0 km/h
Fuel tank capacity105 L
Fuel typediesel
- Low running costs and high reliability.
- Genuine spare parts readily available.
- Factory warranty and full technical support.
