Bulldozer
SHANTUI SD22 – Bulldozer
Transmissionmanual (3 forward / 3 reverse)
Operating weight23,450 kg
Weight with ripper27,000 kg
EngineCUMMINS (189.5 kW / 254 hp)
Hydraulic systemLINDE
The SHANTUI SD22 Dozer is built for intensive earthmoving applications where power, durability, and reliability are essential. Its powerful Cummins engine, high traction force, and robust construction deliver outstanding performance when moving large volumes of material.
Designed to operate efficiently in challenging terrain, it provides dependable performance under continuous heavy-duty workloads. The SHANTUI SD22 is an ideal solution for quarries, road construction, mining, and large-scale infrastructure projects.
Designed to operate efficiently in challenging terrain, it provides dependable performance under continuous heavy-duty workloads. The SHANTUI SD22 is an ideal solution for quarries, road construction, mining, and large-scale infrastructure projects.
Transmissionmanual (3 forward / 3 reverse)
Operating weight23,450 kg
Weight with ripper27,000 kg
EngineCUMMINS (189.5 kW / 254 hp)
Hydraulic systemLINDE
SafetyROPS/FOPS
Joystick controlsno
Air conditioning/heatingyes
Blade capacity4.6 m³
Digging depth540 mm
Blade lift height1210 mm
Digging angle55-58 degrees
Overall dimensions5495x3540x3000 mm
Fuel tank capacity450 L
Fuel typediesel
Custom configurationyes
- Low running costs and high reliability.
- Genuine spare parts readily available.
- Factory warranty and full technical support.
